Shortcut Trick
In a cyclic quadrilateral, the sum of opposite angles is 180°.
⇒ ∠B = 180° − ∠D = 180° − 129° = 51°
Since AB is the diameter, the angle subtended in the semicircle is a right angle:
⇒ ∠ACB = 90°
In right-angled triangle ABC, the acute angles are complementary:
⇒ ∠BAC = 90° − ∠B = 90° − 51° = 39°
∴ The correct answer is 39°.
Alternate Method
Given:
ABCD is a cyclic quadrilateral where AB is the diameter of the circle.
∠ADC = 129°
Formula/Theorem Used:
- Opposite angles theorem: The sum of opposite angles of a cyclic quadrilateral is 180°.
- Angle in a semicircle: The angle subtended by a diameter at any point on the circumference is 90°.
- Angle sum property: The sum of all interior angles of a triangle is 180°.
Calculations:
Since ABCD is a cyclic quadrilateral, the opposite angles ∠ADC and ∠ABC must sum to 180°:
⇒ ∠ADC + ∠ABC = 180°
Substitute the given value of ∠ADC = 129° into the equation:
⇒ 129° + ∠ABC = 180°
⇒ ∠ABC = 180° − 129°
⇒ ∠ABC = 51°
Since AB is the diameter of the circle, the angle subtended by it at point C on the circumference is a right angle:
⇒ ∠ACB = 90°
Now, in triangle ABC, the sum of all interior angles is 180°:
⇒ ∠BAC + ∠ACB + ∠ABC = 180°
Substitute the values of ∠ACB = 90° and ∠ABC = 51°:
⇒ ∠BAC + 90° + 51° = 180°
⇒ ∠BAC + 141° = 180°
⇒ ∠BAC = 180° − 141°
⇒ ∠BAC = 39°
Option Analysis:
• Option (1) 39° is correct because ∠BAC = 180° − (∠ACB + ∠ABC) = 180° − (90° + 51°) = 39°.
• Option (2) 49° is incorrect because it would imply ∠ABC = 41°, which contradicts the cyclic quadrilateral property where ∠ABC = 180° − 129° = 51°.
• Option (3) 41° is incorrect because it would mean ∠ABC = 49°, which does not satisfy ∠ABC + ∠ADC = 180°.
• Option (4) 51° is incorrect because 51° is the measure of ∠ABC, not ∠BAC.
∴ The correct answer is 39°.
Additional Information
Cyclic Quadrilateral Properties
A quadrilateral is cyclic if all its four vertices lie on a single circle. The sum of opposite angles is always 180° (∠A + ∠C = 180° and ∠B + ∠D = 180°).
Angle in a Semicircle
An angle inscribed in a semicircle is always a right angle (90°). This is a special case of the inscribed angle theorem where the central angle is 180°.
Exterior Angle of a Cyclic Quadrilateral
The exterior angle formed by extending one side of a cyclic quadrilateral is equal to the interior opposite angle.
