Magnetic field lines are ___________.
- AOption (a)
closed curves
- BOption (b)
straight lines
- COption (c)
open loops
- DOption (d)
Dots
View answer & explanationHide answer & explanation
Correct answer
closed curves
Why this answer is correct
The correct answer is closed curves.
Key Points
Magnetic field lines:
- A magnetic field line is an imaginary line such that tangent to it at any point gives the direction of the magnetic field at that point in space.
- Magnetic field lines are drawn to represent the magnetic fields.
- Magnetic field lines can be drawn with the help of a magnetic compass.
- Magnetic field lines are also called magnetic lines of force.
Additional Information
Properties of magnetic field lines:
- The magnetic field lines of a magnet (or a solenoid) form continuous closed loops.
- The magnetic field lines start from the north pole and end on a south pole outside the magnet. Inside the magnet, the magnetic field lines start from the south pole and end on the north pole.
- The tangent to the field line at a given point represents the direction of the net magnetic field B at that point.
- The larger the number of field lines crossing per unit area, the stronger is the magnitude of the magnetic field B.
- The magnetic field lines do not intersect with each other if they did, there will be two directions of the magnetic field at that point which is not possible.
