The principal focus of a concave mirror is the point where:
- ((a))
Rays parallel to the principal axis appear to diverge after reflection
- ((b))
The mirror surface intersects the principal axis
- ((c))
Rays parallel to the principal axis converge after reflection
- ((d))
Rays passing through the center of curvature converge
Show Answer
Rays parallel to the principal axis converge after reflection
The correct answer is Rays parallel to the principal axis converge after reflection.

Key Points
- A concave mirror is a spherical mirror whose reflecting surface is curved inwards, facing towards the center of the sphere. It is also known as a converging mirror because it converges the light rays incident on it.
- The Principal Focus (F) of a concave mirror is a specific point on its principal axis. When rays of light coming from infinity or a distant source are parallel to the principal axis, they strike the mirror and, after reflection, actually meet or converge at this point. Hence, statement 3 is correct.
- Unlike a convex mirror, the focus of a concave mirror is a real focus because the light rays actually pass through it. It is situated in front of the reflecting surface.
- The distance from the pole (P) of the mirror to the principal focus (F) is called the focal length (f) of the mirror.
- The principal axis is the straight line passing through the pole and the center of curvature of the spherical mirror.

Additional Information
- Components of Spherical Mirrors:
- Pole (P): The center of the reflecting surface of a spherical mirror. The intersection of the mirror surface and the principal axis defines this point. Hence, statement 2 describes the pole and is incorrect.
- Center of Curvature (C): The center of the hollow sphere of which the mirror is a part. For a concave mirror, it lies in front of it, while for a convex mirror, it lies behind it.
- Radius of Curvature (R): The distance between the pole and the center of curvature.
- Rules of Reflection:
- A ray passing through the center of curvature of a concave mirror is reflected back along the same path because it hits the mirror at an angle of incidence of 0 degrees (perpendicular to the surface). It does not converge at the focus upon reflection from C. Hence, statement 4 is incorrect.
- In a convex mirror, rays parallel to the principal axis diverge after reflection and only appear to originate from the focus located behind the mirror. Hence, statement 1 describes a convex mirror and is incorrect.
- Image Formation: Concave mirrors can form both real and virtual images, as well as magnified or diminished images, depending on the position of the object relative to the focus and center of curvature.

Important Points
- Mathematical Relation: For spherical mirrors with small apertures, the radius of curvature (R) is exactly twice the focal length (f), represented by the formula R = 2f.
- Uses of Concave Mirrors:
- They are commonly used in torches, search-lights, and vehicle headlights to get powerful parallel beams of light.
- They are used as shaving mirrors to see a larger image of the face.
- Dentists use concave mirrors to see enlarged images of the teeth of patients.
- Large concave mirrors are used to concentrate sunlight to produce heat in solar furnaces.
- Sign Convention: According to the New Cartesian Sign Convention, the focal length of a concave mirror is always taken as negative, whereas for a convex mirror, it is positive.
