An electric heater draws 5 A of current when connected to a 70 V source. If the potential difference is increased to 126 V, what will be the new current drawn by the heater?
- ((a))
9 A
- ((b))
3 A
- ((c))
8 A
- ((d))
90 A
Show Answer
9 A
The correct answer is 9 A.

Key Points
- The relationship between voltage (V), current (I), and resistance (R) in an electrical circuit is governed by Ohm's Law, which states that V = IR.
- In the first scenario, the electric heater is connected to a 70 V source and draws a current of 5 A. Using these values, we can calculate the resistance (R) of the heater's heating element: R = V / I = 70 / 5 = 14 Ohm.
- The resistance of the heater remains constant because it is a physical property of the material used in the heating coil (assuming the temperature change doesn't significantly alter the resistance for this calculation).
- In the second scenario, the potential difference is increased to 126 V. To find the new current, we apply Ohm's Law again using the previously calculated resistance: I = V / R.
- By substituting the new values, we get I = 126 / 14 = 9 A. Thus, the new current drawn by the heater is 9 A. Hence, the calculation confirms the correct answer is 9 A.

Additional Information
- Ohm's Law:
- Formulated by German physicist Georg Simon Ohm in 1827, it states that the current through a conductor between two points is directly proportional to the voltage across the two points, provided physical conditions like temperature remain constant.
- The SI unit of resistance is the Ohm (Ω), the unit of potential difference is the Volt (V), and the unit of current is the Ampere (A).
- Resistance Factors:
- The resistance of a conductor depends on its length, cross-sectional area, nature of the material, and temperature.
- In heating appliances like electric heaters, irons, and toasters, the coils are typically made of alloys like Nichrome because they have high resistance and do not oxidize (burn) easily at high temperatures.
- Linear Relationship:
- In an Ohmic conductor, a graph plotted between Voltage (V) and Current (I) results in a straight line passing through the origin, where the slope of the line represents the resistance.

Important Points
- Power Calculation: The power consumed by the heater also changes with voltage. Using the formula P = VI, the initial power was 70 * 5 = 350 Watts, while the new power is 126 * 9 = 1134 Watts.
- Safety Considerations: When voltage is nearly doubled (from 70 V to 126 V), the current also increases proportionally. In real-world applications, this could lead to overheating or tripping a circuit breaker if the wire's current rating is exceeded.
- Application: This principle is crucial for the design of voltage stabilizers and transformers, which ensure that appliances receive the correct potential difference to operate at their rated current.
