P and Q are two points on the ground on either side of a pole. The angles of elevation of the top of the pole as observed from P and Q are 60° and 30°, respectively and the distance between them is 84√3 m. What is the height (in m) of the pole?
- AOption (a)
60
- BOption (b)
52.5
- COption (c)
73.5
- DOption (d)
63
View answer & explanationHide answer & explanation
Correct answer
63
Why this answer is correct
Shortcut Trick Ratio of Base to Height for 60° is 1 : √3 and for 30° is √3 : 1. To keep height constant (√3), ratios become: (1 : √3) and (3 : √3). Total distance ratio = 1 + 3 = 4 units. 4 units = 84√3 m ⇒ 1 unit = 21√3 m. Height = √3 units = 21√3 × √3 = 21 × 3 = 63 m. ∴ The correct answer is 63 m.
Alternate Method Given: Angle of elevation from P (θ1) = 60° Angle of elevation from Q (θ2) = 30° Total distance PQ = 84√3 m Formula Used: Height of pole (h) = d ÷ (cot θ1 + cot θ2) [When points are on opposite sides]
Let height of the pole AB be h m. In right ▵ABP: ⇒ cot 60° = BP ÷ AB ⇒ 1 ÷ √3 = BP ÷ h ⇒ BP = h ÷ √3 In right ▵ABQ: ⇒ cot 30° = BQ ÷ AB ⇒ √3 = BQ ÷ h ⇒ BQ = h√3 Given PQ = BP + BQ = 84√3 m: ⇒ (h ÷ √3) + h√3 = 84√3 ⇒ (h + 3h) ÷ √3 = 84√3 ⇒ 4h = 84 × 3 ⇒ h = 21 × 3 ⇒ h = 63 m ∴ The correct answer is 63 m.
Additional Information Distance Formula (Opposite Sides) If two points are on opposite sides of a pole of height h, then the distance between them is d = h(cot α + cot β). Distance Formula (Same Side) If two points are on the same side of a pole, then the distance between them is d = h(cot β − cot α), where α > β. Standard Trigonometric Ratios tan 30° = 1/√3, tan 45° = 1, tan 60° = √3. cot θ = 1/tan θ.
